WAVE HORIZON 650D Infrared Dual-Lens Thermal Monocular

WAVE HORIZON 650D Infrared Dual-Lens Thermal Monocular

The WAVE HORIZON 650D delivers maximum precision and rugged performance in a compact thermal monocular built for hunters, professionals, and tactical operators. Featuring a high-resolution 640×512 12μm sensor with <15mK NETD sensitivity, it provides crystal-clear imaging even in fog and high humidity.

Its dual-lens system (25mm and 50mm, both f/0.9) offers unmatched versatility. Scan wide terrain with the 25mm lens for a 930’ field of view, or switch to the 50mm lens for detailed long-range detection beyond 2800 yards. Intelligent features include AI-powered ranging with target tagging, onboard recording, and real-time streaming through the WAVE Infrared App. Built with mil-spec magnesium housing and backed by a 5-Year Transferable Warranty, the Horizon 650D redefines field performance.

Key Features

• UPG Germanium Objective Lens for maximum thermal transfer and 100% sensor utilization
• Dual-Lens System (25mm and 50mm) for wide and long-range versatility
• Sixth-Generation 12μm Thermal Sensor with sub-15mK NETD sensitivity
• Joystick Control for intuitive operation in the dark
• Compact One-Hand Design with top-knob focus for quick adjustments
• AI Range Estimator with Target Tagging for instant precision ranging
• Advanced Digital Zoom with 4x capability
• Rugged Magnesium Construction for durability and heat dissipation
• Common 18650 Battery Power with included charger and 9+ hours runtime
• Onboard Charging via wall, vehicle, or power bank
• Photo, Video, and Audio Recording with 64GB internal memory
• WAVE Infrared App for remote streaming, management, and updates
• IP67 Waterproof Rating for all-weather use

Specifications

• Sensor Resolution: 640 × 512
• Pixel Pitch: 12μm
• NETD: <15mK
• Spectral Range: 750–1400μm
• Refresh Rate: 50Hz
• Detection Range: >2800 yards (50mm)
• Objective Lens: 25mm / f0.9 and 50mm / f0.9
• Magnification: 1.5–6.0x (25mm) / 3.0–12.0x (50mm)
• Field of View: 930’ @ 1000 yards (25mm) / 465’ @ 1000 yards (50mm)
• Housing: Magnesium
• Eye Relief: 50mm
• Exit Pupil: 6.6mm
• Display: HD AMOLED, 1024 × 768
• Recording: Photo/Video/Audio with 64GB internal memory
• Color Palettes: 6 (White, Black, Red, Green, Violet, Gold)
• Stabilization: Yes
• Digital Zoom: 4x
• USB-C Data Output: Yes
• Size/Weight: 7.4 in / 23 oz
• AI Ranging with Target Tagging: Yes
• Wi-Fi Connectivity: 100’ range
• Tripod Mountable: Yes
• Battery: (1) 18650 protected, 9+ hours runtime
• Internal Battery: Yes
• Waterproof Rating: IP67
• Operational Temps: -20°F to 130°F
• App Support: WAVE Infrared App (iOS/Android) with live streaming
